5. Polarisation Procedure

This method regroups the different steps presented previously to automate the analysis. The aim is to “press a button” to analyze your results while you enjoy a coffee, tea, or hot chocolate. However, before reaching that level of automation, it is recommended to test and understand the many parameters involved. Many of them can be chosen automatically, but verifying each step yourself ensures reliability.

The main function is analyze_run.polarisation_intensity. Below, we describe the arguments you can pass to this function, corresponding to different steps in the procedure.

This procedure is explained in Part III of the tutorial_spectra_analysis tutorial.

analyze_run.polarisation_intensity(directory=False, L_filename=False, prefix_file=False, L_files_angles=False, N_iter=False, extension='.dat', fct_name=<function standard_file_name>, type_cleaning='mean', L_mean_cleaning_n=[1, 1, 1, 3], L_mean_cleaning_evo_max=[2, 1.5, 1.4, 1.3], automatic_l_cut=True, l_cut=[380, 395, 419, 433], l_cut_n_n2=[2, 9], order_fit_noise=4, method_fit_first='fit_gauss', bounds_fit_gausse=([0, 395, 1], [inf, 410, 25]), lambda_0_ref=403, waist_ref=2, exclu_zone=False, fixed_para_gauss_fit=True, method_fit_second='fit_gauss', save_result=True, name_save_result='./post_prod_results.p', waiting_time=False, show_figure=True)[source]

5.1. Overview of the procedure

  1. Open all the files and verify they are correctly read using alpaga.find_angle_iter_from_dir (see File Management). This step can be bypassed if you define custom values.

  2. Perform a first analysis for all polarization angles. For each angle, the function will: a) clean and average the acquisition, b) remove the noise, c) fit the Gaussian peak.

  3. Perform a second analysis, similar to step 2, where some Gaussian fit parameters can be fixed to the average values. This step is optional.

  4. Save the results in a dictionary.

_images/alpaga_beau_1.jpg

5.2. File selection

This function expects data organized by polarization angle. See the File Management for details. You can either: 1) rely on automatic file detection by Alpaga (see tutorial_spectra_analysis III.A), 2) provide all the information alongside your filename construction (see tutorial_spectra_analysis III.B), or 3) provide the filenames directly (see tutorial_spectra_analysis III.C).

  1. Only requires directory (automatic detection).

  2. Requires prefix_file, L_files_angles, N_iter, and extension. Optionally, fct_name depending on your filename convention.

  3. Requires L_filename, L_files_angles, and N_iter (direct file paths).

  • directory: str or bool Directory containing the data to analyze. Only one experiment per directory is recommended. If set to False, the function will not search for files automatically; you must provide prefix_file, L_files_angles, N_iter, and extension.

  • prefix_file: str or bool If False, the prefix is determined automatically. Otherwise, the string is used as the global file prefix.

  • L_files_angles: list or bool If False, the angles are determined automatically. Otherwise, the provided list is used.

  • N_iter: int or bool Number of acquisitions per angle. Can be provided manually or determined automatically.

  • extension: str File extension, default is ‘.dat’.

  • fct_name: function Function to build filenames. Default is file_management.standard_file_name. See File Management for alternative naming schemes.

  • L_filename: list of lists of strings If your files use a non-standard naming convention, provide the full paths for each angle and iteration. See File Management for details and section III.C of tutorial_spectra_analysis for example usage.

5.3. Averaging and cleaning

Cleaning parameters are applied for each angle:

  • type_cleaning: str, default ‘mean’

  • L_mean_cleaning_n: list

  • L_mean_cleaning_evo_max: list

For details, see Cleaning and Averaging Spectra.

5.4. Noise removal and Gaussian fit

5.4.1. Overview

This section describes the noise management and Gaussian extraction. These numerical steps have the largest impact on the results, so Alpaga provides a semi-automatic procedure to reduce operator choices and improve reproducibility.

  • Spectra are processed per polarization angle.

  • The goal is to extract peak intensity, central wavelength λ₀, and Gaussian width (waist).

  • The process is performed in two runs for robustness and to allow automated l_cut selection.

_images/alpaga_beau_2.jpg

5.4.2. Input parameters

  • l_cut: list of 4 numbers Defines the initial noise and signal regions. See alpaga.remove_noise function.

  • order_fit_noise: int Polynomial order for fitting the noise in the spectra.

  • bounds_fit_gausse: list or tuple Bounds for Gaussian curve fitting. See alpaga.fit_gaussian_from_noise function.

  • lambda_0_ref: float Reference lambda_0 used in the integral method.

  • waist_ref: float Reference waist used in the integral method.

  • method_fit_first: str (‘fit_gauss’ or ‘integral_gauss’) Controls the method for the first run to extract Gaussian parameters.

  • automatic_l_cut: bool If True, a second analysis for each angle is performed using lambda_0 and waist from the first run.

  • l_cut_n_n2: list [n, n2] Parameters defining the Gaussian-based regions for automatic l_cut.

  • fixed_para_gauss_fit: bool If True, a second run is performed with lambda_0 and waist fixed to mean values.

  • method_fit_second: str (‘fit_gauss’, ‘integral_gauss’ or ‘both’) Method for the second run where lambda_0 and waist are fixed.

  • exclu_zone: @MAXIME EXCLUZONE TODO

  • show_figure: bool If True, figures are shown. Controls show_figure_fit_gauss internally.

5.4.3. First run

The first run processes each angle to determine Gaussian parameters and optionally define automatic l_cut.

  1. If automatic_l_cut=False - Uses the l_cut values directly. - Removes noise and fits Gaussian for each angle.

  2. If automatic_l_cut=True - In addition, computes lambda_0 and waist for each angle using initial l_cut.

  • Output parameters per angle: - L_intensity_angle: Gaussian peak intensity - L_lambda_0_angle: lambda_0 - L_waist_angle: Gaussian waist - Error estimates for each above - LL_noise_param: polynomial coefficients for noise fit

5.4.4. Second run

The second run is optional (fixed_para_gauss_fit=True) and fixes lambda_0 and waist to their mean values across all angles. First, it recalculates l_cut based on [lambda_0 - n2*waist, lambda_0 - n*waist, lambda_0 + n*waist, lambda_0 + n2*waist] with the value obtained in the first run. Then, it performs a second fit using this Gaussian-based l_cut.

  • Method: controlled by method_fit_second. - ‘fit_gauss’: curve fitting with lambda_0 and waist fixed, only intensity free. - ‘integral_gauss’: integral method using mean waist. - ‘both’: performs both analyses.

  • Automatic l_cut: if automatic_l_cut=True, l_cut is recalculated using mean lambda_0 and waist.

  • Output parameters per angle: - L_intensity_fit_gauss_fixed_para and _error - L_intensity_integral_gauss_fixed_para and _error

Note

The second run ensures more consistent intensity measurements across angles and is particularly useful when using the integral method.

5.4.5. Recommendation

We recommend using the intensity computed after the second run, with fixed lambda_0 and waist:

  • method_fit_first = ‘fit_gauss’

  • automatic_l_cut = True

  • method_fit_second = ‘fit_gauss’

  • fixed_para_gauss_fit = True

Note

This combination is recommended because the first run with ‘fit_gauss’ reliably determines lambda_0 and waist, the automatic_l_cut ensures robust noise areas, and the second run with fixed parameters avoids angle-dependent fluctuations.

The obtained intensity is saved as: L_post_prod[‘L_intensity_fit_gauss_fixed_para’].

5.5. Saving results

The results and input arguments are saved in a dictionary, which can also be exported as a pickle file.

  • save_result: bool If True, results are saved using the name specified in name_save_result.

  • name_save_result: str Full path to the pickle file where results and parameters are stored. Must end with ‘.p’. Example:

    name_save_result = '/home/lama/Datas/Results/my_results.p'


Once saved, the results can be loaded in Python:

with open(name_save_result, "rb") as filetoload:
    L_post_prod_load = pickle.load(filetoload)

Key entries in the dictionary:

  • L_intensity_angle: intensity I0 for each angle (first analysis)

  • L_lambda_0_angle: Gaussian peak position for each angle (first analysis)

  • L_waist_angle: Gaussian width for each angle (first analysis)

If automatic_l_cut = True, these correspond to the second noise-removal analysis using n and n2.

Second analysis (if fixed_para_gauss_fit = True):

  • L_intensity_angle_fit_gauss_fixed_para: intensity with Gaussian fit, lambda_0 and waist fixed

  • L_intensity_angle_integral_gauss_fixed_para: intensity using integral method with lambda_0 and waist fixed

Other saved information:

  • LL_noise_param: polynomial coefficients for noise fits

5.6. Other parameters

While the function is running, several plots and messages are displayed. These are meant to help monitor the analysis and debug if necessary.

  • waiting_time: float or bool If set to a float, the function pauses this many seconds between each angle to allow inspection of plots. If False, the code runs without intentional pauses.

_images/alpaga_19.jpg
