2. File Management

In this page, we explain how data are handled by Alpaga: first, how the data are expected to be stored and named, and then how to access them to start the analysis procedure.

2.1. Expected Data Structure

The numerical procedure is built around the experimental setup.

For a given analyzer angle (either V/H or S/P, depending on your terminology) of the 2-omega photon and other experimental parameters (fundamental power, sample, temperature, number of surfactant/layer per square meter), a directory contains the measured spectra for one or more incoming polarization angles.

In this directory, the “angle” can take arbitrary values, as long as the file names follow this structure:

prefix_angle-value_iter-number.extension

This structure is defined through several internal functions, particularly the alpaga.file_management.standard_file_name function:

file_management.standard_file_name(prefixe, angle=False, iteration=False, extension='.dat')[source]

Define how to build the file name of an acquisition.

You may define your own function if your file does not follow the same structure. However, we strongly recommend using the same input/output format as described below:

Parameters:

  • prefixe (str) – The prefix of the file name.

  • angle (str or bool) – [Optional] If not a bool, appends this ‘angle’ value to the file name.

  • iteration (str or bool) – [Optional] If not a bool, appends this ‘iteration’ value to the file name.

  • extension (str) – [Optional] The extension of the spectra file. Default is ‘.dat’.

Returns:

name – The generated file name.

Return type:

str

Example

For this standard function, if the input is:

prefixe = ‘polarV’ angle = ‘42.0’ iteration = ‘4’ extension = ‘.dat’

The output will be: ‘polarV_42.0_4.dat’

You can define another file-naming structure if needed (see the last section).

For example, in the directory:

/home/lama/Datas/Water_acquisition/V_analyser

the files may include:

spectra_water_v_2.0_1.dat, spectra_water_v_2.0_2.dat, spectra_water_v_4.0_1.dat, spectra_water_v_4.0_2.dat, spectra_water_v_6.0_1.dat, spectra_water_v_6.0_2.dat.

Here: - The prefix for all these files is /home/lama/Datas/Water_acquisition/V_analyser/spectra_water_v. - The list of angles is [2.0, 4.0, 6.0]. - The total number of iterations is 2.

Warning

The Alpaga developers strongly recommend always using an absolute path to your data rather than a relative one. For instance, if you run the code in /home/lama/Datas/Water_acquisition, you could use a shorter prefix such as V_analyser/spectra_water_v. However, using the full path /home/lama/Datas/Water_acquisition/V_analyser/spectra_water_v is more stable.

The angles can be any string; you can encode other varying properties using this framework. The “list of angles” does not need to be bounded or evenly distributed. Be aware, however, that the final analysis (from the experimental data to the real observable you want, such as the i4 or surface susceptibility) may not work as expected if the angles are irregular.

Note

Alpaga can process all or only a subset of the available angles in a directory. See this page for more information.

_images/alpaga_6.jpg

For each acquisition with the same experimental parameters (for example, angle=2.0), several acquisitions are made in order to average the spectra. See the cleaning procedure for more details. These acquisitions are stored using different iteration numbers, from 1 to N. In this example, there are 2 iterations: spectra_water_v_2.0_1.dat and spectra_water_v_2.0_2.dat, which will be used to compute a cleaned spectrum for the angle value 2.0.

Note

For all angles, the exact same number of iterations should be available. If you want to average over fewer iterations than available, you can redefine it using iter_number. See the cleaning procedure.

Note

In the tutorials and in the code, the number of iteration is often stored in N_iter.

Now that we have described the data structure, let’s be more explicit. First, we show how to open a “single acquisition” (i.e., for a given angle) with file names like prefix_iter-number.extension. Then, we show how to handle acquisitions for multiple angles, with file names like prefix_angle-value_iter-number.extension. The output from these functions is used later in the procedure.

2.2. Open Single Acquisition

To get the Alpaga parameters for processing a single acquisition located in a directory, use the function:

file_management.find_file_iter_from_dir(directory, extension='.dat')[source]

Return the prefix (prefix_file), the number of iterations (N_iter), and the extension (extension) of a single acquisition located in the directory directory.

The expected file naming convention is:

directory + prefix + ‘_’ + i + extension

where i ranges from 1 to N_iter.

Parameters:

  • directory (str) – The directory where the data is stored.

  • extension (str) – [Optional] The extension of the spectra file. Default is ‘.dat’.

Returns:

  • prefix_file (str) – The prefix shared by all the spectra iterations.

  • N_iter (int) – The number of iterations found for this prefix. Alpaga checks that all iterations are present to avoid ‘File not found’ errors later on.

  • extension (str) – The extension of the detected spectra file. Same value as the input.

Examples

Suppose that in the directory /home/lama/Datas/Water_acquisition/Test_120sec there are the spectra files: water_1.dat, water_2.dat, water_3.dat.

The prefix of these files is water, the total number of iterations is N_iter = 3, and the extension is .dat.

To automatically extract this information, use:

directory = '/home/lama/Datas/Water_acquisition/Test_120sec'
prefix, N_iter, extension = alpaga.find_file_iter_from_dir(directory)
print('The prefix for all files is: "' + prefix + '" with '
      + str(N_iter) + ' iterations. The extension is: ' + extension)

2.3. Open Angle Acquisition

To get the Alpaga parameters for processing acquisitions with multiple angles located in a directory, use the function:

file_management.find_angle_iter_from_dir(directory, extension='.dat')[source]

Return the prefix (prefix_file), the list of angles (L_files_angles), the number of iterations (N_iter), and the extension (extension) of an acquisition located in the directory directory.

The expected file naming convention is:

directory + prefix + ‘_’ + k + ‘_’ + i + extension

where k iterates over all values in L_files_angles (angles, possibly floats — avoid excessively long decimal values), and i ranges from 1 to N_iter.

Parameters:

  • directory (str) – The directory where the data is stored.

  • extension (str) – [Optional] The extension of the spectra file. Default is ‘.dat’.

Returns:

  • prefix_file (str) – The prefix shared by all spectra iterations.

  • L_files_angles (list of str) – The list of detected angles. Returned as a list of strings (to avoid issues with filenames such as ‘4.10’).

  • N_iter (int) – The number of iterations found for this prefix. Alpaga checks that all iterations are present for all angles to avoid ‘File not found’ errors later on.

  • extension (str) – The extension of the detected spectra file. Same as the input value.

Examples

Suppose that in the directory /home/lama/Datas/Water_acquisition/Test_120sec the following spectra files are located:

water_4.0_1.dat, water_4.0_2.dat, water_15.0_1.dat, water_15.0_2.dat.

The prefix of these files is water, the total number of iterations is N_iter = 2, the list of angles is L_files_angles = [‘4.0’, ‘15.0’], and the extension is .dat.

To automatically extract this information, use:

directory = '/home/lama/Datas/Water_acquisition/Test_120sec'
prefix, L_files_angles, N_iter, extension = alpaga.find_angle_iter_from_dir(directory)
print('The prefix for all files is: "' + prefix + '" with '
      + str(N_iter) + ' iterations. The angles found are '
      + str(L_files_angles) + '. The extension is: ' + extension)
_images/alpaga_11.jpg

2.4. Define Your Own Set of Files

To go further, you need to define a general prefix, a list of angles, the number of iterations, and the file extension. If you followed the previous procedure, be sure to include the full path in the prefix, i.e.:

prefix_general = os.path.join(directory, prefix)

If you want to set these values manually, you can. This may be useful if you built your own procedure using only parts of Alpaga (in which case, you should be comfortable with Python and may not need further guidance), or if you want to set the initial parameters for the automated procedure alpaga.polarisation_intensity (see here).

Furthermore, if your file naming structure differs from the standard Alpaga format, you can still use the majority of the code, except for the alpaga.find_file_iter_from_dir and alpaga.find_angle_iter_from_dir functions. To do so, you must define your own function that specifies how to construct a file name given a prefix, angle, iteration, and extension. In other words, you define your own equivalent of alpaga.standard_file_name. See the tutorial for more examples.

To use your custom function and replace the standard naming structure, provide it through the optional argument fct_name in the alpaga.averaging_and_cleaning and alpaga.polarisation_intensity functions.

2.5. Different Naming Conventions

If your file naming convention differs significantly from the standard Alpaga format, you must provide the full path to each acquisition as an N_angle x N_iter list. For example, for 2 angles and 3 iterations:

L_filename = [
    [filename_angle1_iter1, filename_angle1_iter2, filename_angle1_iter3],
    [filename_angle2_iter1, filename_angle2_iter2, filename_angle2_iter3]
]

With the correct number of iterations (N_iter) and any list of angles:

L_files_angles = ['angle_value_1', 'angle_value_2']
N_iter = 3

Note

If you provide your data in this way, be careful when following the tutorial_spectra_analysis tutorial, especially during the denoising step (Part I.B and I.C) and when using the the core function Alpaga.analyze_run.polarisation_intensity (Parts III.B and III.C).


The next procedure step is to average the clean every spectrum and to perform the average over all the acquisition (N_iter).
